Various cold-formed metal framing configurations illustrate built-up posts and beams joined with number ten self-drilling screws spaced at twelve inches on center. The assemblies include back-to-back studs, toe-to-toe studs, box bundles, and triple stud bundles tied together with tracks matching the stud gauge where required. Fastening details show two rows of screws spaced at twelve inches on center along flanges and webs, supplemented by hanger tracks and specific notes regarding plate requirements.
#10 @ 12" O.C. E.S. 2 ROWS #10 @ 12" O.C. TRACK WHERE OCCURS TRACK TO MATCH STUD GAUGE (2) ROWS #10 @12" 0.C. (3) BUNDLE BOX B (2) BUNDLE BACK-TO-BACK F (3) BUNDLE E 1/4 2-12 EA. SIDE TRACK WHERE OCCURS #10 @ 12" O.C. E.S. A SCREWED TOE-TO-TOE C SCREWED BACK-TO-BACK D SCREWED DBL. JOIST ¯ TO MATCH STUD GAUGE #10 @ 12" O.C. E.S. 2 ROWS # 10 @ 12" O.C. TRACK WHERE OCCURS (2) ROWS # 10 @ 12" 0.C. NOTE : ¯ NOT REQUIRED AT TRACKS #10 @ 12" O.C. E.S. TRACK TO MATCH STUD GAUGE 2 ROWS #10 @ 12" O.C. HANGER TRACK TO MATCH STUD GAUGE WHERE OCCURS PER PLAN
