Dowel laminated timber floor slabs bear directly on structural steel wide-flange beams at cantilever conditions. The dowel laminated timber designer provides uplift-resistant connections between the timber slab and the steel beam where required to resist unbalanced live loads. Additional uplift connectors may be required per the timber consultant. Sheet 20/S-G01 provides additional general information and standard details.
STL BM, TYP SEE FOR ADDL INFO 20/S-G01 SEE PLAN DLT DESIGNER TO PROVIDE UPLIFT RESISTANT CONN BTWN DLT AND STL BM WHERE REQD TO RESIST UNBALANCED LIVE LOAD AT THE CANTILEVER. UPLIFT CONNECTOR MAY BE REQUD PER TIMBER CONSULTANT NOTES: 1. SEE "TYPICAL TIMBER FLOOR SLAB" FOR ADDITIONAL INFORMATION. PER PLAN TOC
