Roof edge transition where a metal roof deck bears on an open-web steel joist supported by a wide-flange steel beam. A continuous three-sixteenths by eight-inch steel plate is secured to six-inch eighteen-gauge cold-formed steel studs spaced at sixteen inches on center using self-tapping screws. Additional self-tapping screws fasten the stud intersections. Steel joist bracing is configured per detail eight on sheet S521. Glazing and related architectural elements are coordinated per architectural drawings.
190381_S522-06 6 EDGE DETAIL AT ROOF AT METAL PANEL GLAZING, SEE ARCH AT GLAZING AT WIDE FLANGE BEAM STEEL BEAM, SEE PLAN METAL ROOF DECK 1/8, 2 AT K-JOIST 1/4, 3 AT LH-JOIST BRACE PER 8/S521 STEEL JOIST, SEE PLAN GLAZING, SEE ARCH STEEL PL 3/16"x8"xCONT WITH (2) #12 STS AT EA STUD (3) #12 STS AT EA STUD INTERSCTION 6"x18GA (600S162-43) METAL STUDS AT 16" O.C., TYP 12A S511 12A S511 SIM SEE ARCH
