A continuous steel grating bears on a continuous steel angle spanning a concrete edge curb formed over a structural steel beam. The continuous angle is anchored with one-half inch diameter by four inch heavy-duty sleeve anchors at twenty-four inches on center. The concrete curb is reinforced with continuous number four rebar, number three standard hooks at sixteen inches on center, and continuous number four rebar at the beam centerline with dimensions verified with the architect. A continuous five-sixteenth inch bent plate is anchored to the vertical face with one-half inch diameter by forty-two inch long deformed bar anchors at eighteen inches on center. Concrete over metal deck ties into the supporting steel beam framing.
W/ ARCH 6" VERIFY W/ ARCH 6" VERIFY BM 12" MAX SEE ARCH CONC OVER MTL DECK #4 x CONT STL GRATING L2X2X3/16XCONT W/ 1/2"Ø X4" HSA AT 24"oc #3 STD HOOK AT 16"oc #4 X CONT STL BM BENT PL 5/16"XCONT W/ 1/2"Ø X 42" LONG DBA's AT 18"oc
