The steel stair stringer is sized per plan and connects to the mid-landing framing with a complete joint penetration weld. Manufactured wood stair treads and the mid-landing panel are provided by others and attach to support plates welded to the stringer. Angles and connections are detailed per sheet S5.06.
MPP MID-LANDING PANEL PER OTHERS STRINGER PER PLAN MPP STAIR TREAD PER OTHERS ANGLE & CONN PER 12/S5.06 CJP
