A steel beam-to-column flange connection occurs at the top of a column. The assembly features a cap plate whose thickness is determined by the greater of the connected flange thicknesses plus one-quarter inch, with a one-inch minimum. Continuity plates are specified to match the larger flange thickness. Shear tabs connect the framing beams to the column flanges where required. Welds tie the top and bottom flanges to the cap plate typical of the connection.
A A BEAM TO COLUMN FLANGE G CONNECTION (TOP OF COLUMN) ELEVATION CONTINUITY PLATES USE LARGER OF TF1 OR TF2 (SEE DETAIL "E") CAP PLATE, THICKNESS = GREATER OF TF1+1/4" OR TF2+1/4" (1" MIN.) TF2 TF1 . C.P. T&B FLANGES, TYP. M CAP PLATE SEE TYP. DETAIL SHEAR TAB WHERE OCCURS
