The drawing shows a flange thickness transition connection with a two-and-a-half to one slope taper joining members of differing thicknesses. A complete joint penetration weld connects the tapered flange transition to the thinner member. The bottom flange is shown, with the top flange handled in the opposite manner.
ALIGNED FLANGE THICKNESS TRANSITION CJP NOTE: BOTTOM FLANGE SHOWN, TOP FLANGE OPPOSITE. 2.5 1 ALIGNED FLANGE THICKNESS TRANSITION CJP NOTE: BOTTOM FLANGE SHOWN, TOP FLANGE OPPOSITE. 2.5 1
