Text on the drawing
FOR SHEAR PL, WELDS, AND FASTENERS, SEE "TYPICAL NON-FRAME BEAM CONNECTION SCHEDULE AND DETAILS" W BEAM PER PLAN W GIRDER PER PLAN W BEAM TO MATCH OPPOSITE W BEAM UNO W GIRDER AND W BEAM WITH EQUAL DEPTH CJP TYP T&B FLANGE B
