A continuous twelve-gauge plate connects a concrete-filled or bare metal deck to a structural steel beam per plan. The continuous plate is welded to the steel beam flange with a one-eighth-inch fillet weld spaced at twelve inches on center max. A steel stud soffit bears below the beam flange alignment. The assembly accommodates edge conditions where the metal deck runs adjacent to structural steel framing.
CONC FILLED OR BARE METAL DECK PER PLAN CONT 12GA PL & TOP CONN PER OR BEAM PER PLAN STEEL STUD SOFFIT EDGE OF BEAM FLANGE 12" MAX OF CONT PL 2" TO END 1/8 2-12 CONT PL TO BEAM 8 S-620 9 S-620
