Case I details a beam bracing connection utilizing an L3x3x1/4 angle strut tied to the supporting wide-flange member with a one-quarter-inch plate and three-quarter-inch diameter top and bottom bolts, welded with three-sixteenth-inch fillet welds. Case II details a standard beam connection configuration governed by dimension X relative to twelve inches. Notes dictate using Detail a if X is greater than twelve inches and Detail b if X is less than or equal to twelve inches.
