S-D84FY — Detail 4

Structural · S-D84FY

Detail 4

Units: metric
Sheet: S-MB-6.02
Discipline: Structural

Materials

Elements

Beams Bracing Connections / Plates Decks Floors / Slabs Roofs Trusses

Connections

Bracing Connection Deck Attachment Gusset Plate HSS Connection Welded Connection

Text on the drawing

U/S OF DECK - HIGH POINT 108.48 T.O MAIN FLOOR 100.00 MB - T.O. PLATFORM STEEL 102.76 U/S JOISTS AND TRUSSES 106.50 13 S-MB-6.03 BRACING L76x76x6.4 C/W PL 6 GUSSET NESTED & FIELD WELDED TO OWSJ CHORDS T=10kN MIN LOCATION VARIES PLATFORM HANGER ROOF JOIST TYP LLH SEE PLAN FOR EXTENT HSS 152x102x6.4 2756
