Beams frame into a hollow structural section column using a shear plate and flange plates on each side sized per schedule. Beam flanges feature typical dimensional constraints requiring a one-half inch radius where notched, with one inch minimum clear distance and one-and-a-half inch minimum to two inch maximum dimensions at the column face. Flange plates and shear plates are integrated into the assembly to transfer loads through the column joint.
SECTION A-A 1/2" RADIUS WHERE NOTCH REQ'D. TYP. MIN. 1" WHERE NOTCH REQ'D. TYP. 1 1/2" MIN. 2" MAX. TYP. "b" SHEAR PL WHERE OCCURS FLANGE PL EACH SIDE REF. SCHEDULE BEAM FLANGE TYP.
