S-D6RBJ — Section

Structural · S-D6RBJ

Section

Units: metric
Sheet: S-MB-5.23
Discipline: Structural

Materials

Cold-formed Steel Steel

Elements

Arches Beams Ceilings Columns Connections / Plates

Connections

HSS Connection Welded Connection

Text on the drawing

MB-F.1 U/S OF SOFFIT 107.32 SEE ARCH FOR STL STUDS CONT L, SEE PLAN CJP, TYP HSS 152x152x6.4 HSS 203x203x6.4
