Precast concrete wall panels meet at a vertical joint supported by a channel ledger beneath. A 7-inch by 3/4-inch by 1-foot-7-inch plate spans the joint along with a 7-1/2-inch by T-inch by 1-foot-0-inch shim plate. The variable thickness T denotes a shim plate thickness equal to the difference between two panels. Remaining information is referenced to details 1 and 2 on sheet SD.4.
