This assembly details the splice of an angle or double bent plate ledger at a structural steel column. The ledger is positioned against the column flange and secured with a five-sixteenths inch fillet weld. The specific ledger profile is sized per the structural plans.
Text on the drawing
ANGLE OR DBL BENT PLATE LEDGER SEE PLAN 18 - 5/16
