A typical double-cased drilled shaft foundation connection with a pile cap or mat foundation. A forty-eight inch diameter Sonotube form or similar is provided as required by the contractor, surrounded by a one-inch void space typical all around. Two inches of compressible material is positioned beneath the structural mat or pile cap. Reinforcement for both the drilled shaft and the mat or pile cap is omitted from this view.
BART ZOI TYP ALL AROUND 1" VOID SPACE, MAT OR PILE CAP REINF NOT SHOWN DRILLED SHAFT REINF NOT SHOWN 48"ø SONOTUBE FORM OR SIM AS REQD BY CONTR 2" COMPRESSIBLE MATERIAL
