An L4x3x3/8 structural angle connects to a hollow structural section column via a three-eighths-inch steel plate and four bolts. Five-sixteenths-inch fillet welds secure the plate assembly to the column and framing elements, maintaining one-inch clearances.
DETAIL B 5/16 5/16 1" 1" 3/8 PL 5/16 5/16 L4x3x3/8 PL DETAIL B 5/16 5/16 1" 1" 3/8 PL 5/16 5/16 L4x3x3/8 PL
