A roof deck per plan bears over a structural steel beam supported by a concrete masonry unit wall with typical bond beams and vertical reinforcing. A half-inch thick plate matching the flange width is welded to the support with three-sixteenths inch fillet welds near side and far side. A build-up plate per sheet S-507 is provided at the exterior edge alongside an edge detail. Wall panels per architectural drawings A-351 through A-353 attach to the exterior face of the masonry assembly.
1 PER PLAN GRID EP-2 BM PER PLAN 3/16 3/16 NS&FS RF DK PER PLAN ED-1 PL1/2 X FLG WIDTH 8" 1/4 4 1/4 4 WALL PANEL PER ARCH DWG A-351 - A-353 CMU WALL PER PLAN BOND BM TYP PL BUILD-UP PER S-507 S-507 WALL PANEL PER ARCH DWG A-351 - A-353 CMU WALL PER PLAN BOND BM TYP
