A cable brace connects to a structural steel beam via a five-by-five-inch by five-sixteenths-inch plate welded to the beam web with three-sixteenths-inch fillet welds. The cable incorporates a galvanized heavy wire rope thimble and is secured using wire rope clips. A two-inch square by one-quarter-inch washer plate sits beneath a single three-eighths-inch diameter A307 bolt.
CABLE BRACE CONDITION CABLE W/ WIRE ROPE CLIPS 2" SQ x 1/4" WASHER PL & GALV HEAVY WIRE ROPE THIMBLE PLATE 5/16x5x5 W/ (1) 3/8"Ø A307 BOLT 3/16 3/16 B
