A shear plate is connected to a structural support at a skewed angle with fillet welds. The layout indicates a variable skew angle between the connecting plate and the support member. Dimension markers denote the plate thickness and gap clearance at the joint.
B A ANGLE SKEW TP G SHEAR PLATE TYPICAL SUPPORT TYPICAL A FILLET WELD B A ANGLE SKEW TP G SHEAR PLATE TYPICAL SUPPORT TYPICAL A FILLET WELD
