A typical full depth connection plate assembly welded to a wide flange column or beam. Connection plates are welded to the web and flanges using three-eighths inch fillet welds as specified, with corner clips sized according to standard AISC dimensions plus one-half inch. The plate dimensions maintain a specified radius between one-half inch minimum and two inches maximum. Additional welds follow requirements per other project details.
TO WEB TYP WELD PL WELD PL TO FLG, TYP AISC 'k1'+1/2" TYP RADIUS 1/2" MIN 2" MAX, TYP PLATES TYP WF COL OR BEAM (OR OTHER) TYP WELDS PER OTHER DETAILS TYP MIN AISC 'k'+ 1/2" CLIP PL CORNER . 'k'+1/2" AISC 'k'+1 1/2" AISC 3/8 ONLY FILLET WELDS TYP
