A cold-formed steel stud drop assembly attached to a metal deck floor system. The 362S162-54 stud drop is centered at the lower deck flute and anchored with Hilti X-U powder-actuated fasteners embedded a minimum of one and one-quarter inches at six inches on center. The 362T125-54 track is secured with number eight sheet metal screws to each stud on each side. Additional framing utilizes 362S162-54 studs spaced at twenty-four inches on center, requiring no additional bridging or bracing unless otherwise noted. Hanger connections are stabilized with two number eight sheet metal screws at the mid-point and four number eight sheet metal screws at each end hanger, maintaining a two-inch minimum typical clearance.
C D LEVEL 2 327' - 2" 362S162-54 @ 24" OC — NO ADDITIONAL BRIDGING/BRACING IS REQ'D 362S162-54 STUD DROP APPROXIMATELY AT MID-SPAN CENTERED AT LOWER DECK FLUTE HILTI X-U PAF EMBEDED 1-1/4" MIN @ 6" OC 362T125-54 W/ #8 SMS EA STUD EA SIDE TYP 362S162-54 @ 24" OC TYP UNO (2) #8 SMS @ MID- POINT HANGER STUD (4) #8 SMS @ EA END HANGER (2) HILTI X-U PAF @ 24" OC TYP 2" MIN TYP C:\Users\briannas\Documents\SDSC_STRUC_DC_24_BSE_bschildmeyer.rvt 12/5/2025 1:14:51 PM 3/4" = 1'-0" 9 SECTION
