Sloped steel beams carry steel hoist beams connected via typical beam-to-beam framing. Elevation guiderail support columns feature a typical slip connection at the top. Top of steel is set per plan elevations.
T.O.S. PER PLAN SLOPED STL BM STL HOIST BM TYP. BM TO BM CONN. - SEE 6 S5.01 TYP. SLIP CONN. @ TOP OF COL. - SEE 6 S5.02 ELEV. GUIDERAIL SUPPORT COL.
