Cold-formed steel shearwall panel featuring continuous 350S200-54 blocking with two rows of sheathing edge fastening. A maximum 14-1/2-inch wide by 26-1/4-inch tall opening is framed with edge nailing along full stud height on each side, maintaining a minimum 1-4 separation from the panel edge. Edge nailing is specified around the perimeter with field nailing across the panel face. A maximum 6-inch diameter hole is permitted, with edge distance notes referencing structural sheet S-155041.
EDGE NAILING STUD AT JOINT EDGE NAILING FULL STUD HEIGHT AT STUD ON EA. SIDE OF OPENING, TYP. '350S200-54 CONT. BLKG. W/ 2 ROWS SHEATHING EDGE FASTENING - SEE (EXTEND STRAP 32" BEYOND EA. SIDE OF OPENING) SOLE PLATE SHEARWALL PANEL 14 1/2" WIDE x 26 1/4" TALL MAX. (@ 12'-0" MIN. LONG SHEARWALL) 1'-4" MIN. TO PANEL EDGE FROM OPENING EDGE NAILING 6"Ø MAX. HOLE EDGE NAILING SHEARWALL HEIGHT FIELD NAILING SHEARWALL WIDTH 11 S-155041 12" FROM PANEL EDGE MIN. EA. WAY - SEE FOR EDGE DISTANCE <12" 13 S-155041
