This structural section shows a stud wall typical framing connection with a track and anchor sized per the schedule. The concrete fill over a metal deck bears on a wide flange steel beam with weld or fastener hardware connections shown. A non-structural wall panel occurs below, featuring a deflection track connection detailed per sheet S1.4.
GL SAD FLOOR TRACK W/ ANCHOR PER SCHED BM PER PLAN DEFLECTION TRACK CONN PER NON-STRUCTURAL WALL PANEL BY OTHERS, WHERE OCCURS STUD WALL, TYP CONC O/ MTL DECK WHS 9" MAX ¢ BM EDGE OF DECK PER 7 S1.2 10 S1.4
