A vertical double angle member connects to a structural chord member at a common work point using a three-quarter inch gusset plate welded with quarter-inch fillet welds. A web doubler plate of thickness 't' is provided on each side when the gusset plate thickness exceeds the chord web thickness by a quarter-inch or more, welded according to specified formulas. A three-quarter-inch clearance is maintained between the vertical member and the chord, and thirty-degree cut angles are detailed at the plate edges. The bottom chord condition shown is similar but inverted at the top chord.
NOTES: 1. SEE "TYPICAL WELDED TRUSS CONNECTION AT DOUBLE ANGLE WEB MEMBERS" FOR ADDITIONAL INFORMATION. 2. CONDITION SHOWN AT BOTTOM CHORD IS SIMILAR OPPOSITE AT TOP CHORD. 3. WEB DOUBLER PLATE THICKNESS "t" TO BE EQUAL TO THE DIFFERENCE BETWEEN GUSSET THICKNESS AND CHORD WEB THICKNESS. NOT REQUIRED FOR A DIFFERENCE < 1/4". 4. W = t - 1/8 OR AISC MINIMUM, WHICHEVER IS GREATER. WEB DOUBLER PL "t" ES, SEE NOTE 3 NOTE 1 PL 3/4 1/4 1/4 WP CL CHORD SEE NOTE 4, TYP W CG VERT CLR 3/4" 1" TYP TYP 30° 13 TYPICAL DOUBLE ANGLE VERTICAL ONLY CONNECTIONS AT TOP AND BOTTOM CHORD
