Metal deck bears across hollow structural section steel beams with a depth of one and five-sixteenths inches. Self-tapping Teks screws fasten the metal deck to the supporting HSS steel beams following the pattern specified in the roof metal deck notes. A reference bubble directs to detail four for additional metal deck notes.
