A moment-connected steel beam frames into a supporting steel beam with top and bottom flange connections. Weld access holes are provided per AISC 360 standards at the beam flanges. Bolted web connections join the members together, with typical supporting beam depths varying relative to the moment-connected beam.
C.P. U.T. TYP. T&B MOMENT CONNECTED BM FOR DETAILS & CALLOUTS IN COMMON SEE SUPPORTING BM TYPICAL SUPPORTING BEAM DEEPER THAN MOMENT CONNECTED BEAM C.P. U.T. TYP. T&B MOMENT CONNECTED BM FOR DETAILS & CALLOUTS IN COMMON SEE TYPICAL MOMENT CONNECTION SUPPORTING BM WELD ACCESS HOLE PER AISC 360 1 S52-00 1 S52-00
