S-CW7G5 — Enlarged Detail

Structural · S-CW7G5

Enlarged Detail

Units: metric
Sheet: S-MB-8.05
Discipline: Structural

Materials

Elements

Connections / Plates

Connections

Bolted Connection Welded Connection

Text on the drawing

6 51 126 PL 6.35x126x220 LG SQ 300W PL 6.35x50x220 LG SQ 300W 31 82.5 110 5 220 2 HOLES DRILL ON ASSY TO SUIT 1 HOLE 6mm-20 CHAMFER 15X45° 2 PLACES 5 TYP

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
