A truss purlin connects beneath a hollow structural section member sized per plan. The assembly is joined using a one-eighth inch fillet weld with one and one-half inch spacing. Two rows of Pneutek pins are installed at bottom nailer spacing with four lines where required. A section cut B-B is indicated along with a reference to sheet twelve for splice locations.
2 1/2" TRUSS PURLIN B-B 1/8 1 1/2 HSS SEE PLAN FOR SPLICE WHERE OCCURS SEE 12 - (2) ROWS OF PNEUTEK PINS AT BN SPACING (4 LINES WHERE BN
