A structural steel angle L3x3x3/16 is secured to each low flute on each side of the floor opening using a 1/2-inch-diameter expansion bolt with 3-1/2-inch embedment. The metal deck flutes extend a minimum of two flutes past each side of the opening. Additional reinforcing is placed at cores spanning up to 18 inches maximum.
REINFORCING AT CORES TO 18" MAX. 18" MAX. MIN. EACH SIDE EXTEND (2) LOW FLUTES TYP. 1 1/2" L3x3x3/16 w/ 1/2"Ø EXPANSION BOLT w/ 3 1/2" EMBEDMENT AT EACH LOW FLUTE EACH SIDE OF OPENING
