A wide-flange steel column and diagonal core brace connect to a heavy base plate assembly anchored atop a reinforced concrete footing. Ten two-inch diameter ASTM F1554 Grade 105 anchor bolts secure the base plate over a two-inch layer of non-shrink grout and a leveling nut assembly. A robust gusset plate welded to the column flange and base plate ties into the diagonal brace at a designated work point. Half-inch plate stiffeners are welded to the column web and flanges with five-sixteenths inch fillet welds on three sides. Complete joint penetration welds connect the column flanges directly to the base plate.
BRACE SEE ELEV LEVELING NUT AS REQ'D BY CONTRACTOR W.P. 1/2" PL STIFFINERS AT LOCATION NOTED ON CORE BRACE SCHEDULE WF COLUMN SEE ELEV 5/16 3 SIDES TYP GUSSET PL, TYP SEE PLAN T.O. CONC C.J.P. D.C. WELD AT FLANGES, TYP 10 - 2"ø ANCHOR BOLTS ASTM F1554 GRADE 105 PROVIDE 3 1/4"ø HOLES IN BASE PLATE, TYP TOP & BOTTOM BARS PER PLAN SEE PLAN T.O. FTG NON-SHRINK GROUT MIN 2" CLR 3" TYP 3" CLR 5" BENEATH BOTTOM BARS EMBED PLATE 1 1 TYP 1"
