The concrete ramp slab connects to the vertical wall panel using number 4 reinforcing bars at 18 inches on center, anchored 6 inches into the wall panel with Hilti HIT-RE 500-V3 epoxy or equal, per ESR-3814. Special inspection is required for these epoxy anchors. The slab reinforcement consists of number 4 bars at 18 inches on center, which hook into the adjacent vertical concrete element. The wall panel thickness is sized per plan.
