Structural steel framing details show beam-to-column flange and beam-to-beam bolted double angle connections. The bottom flange is coped up to a maximum length with a two-inch minimum clearance to the beam cope when required for erection. Double angles are fastened with bolts spaced at three inches on center typically, maintaining specified clearances to the face of the web and column flange.
SECT SECT COPE BOT FLG ONLY WHEN REQD FOR ERECTION 2L, SEE NOTE 1 1/2" MAX TO BM COPE BEAM TO BEAM SEE "BM TO BM" CONN FOR DIMS 1 1/2" MAX BEAM TO COLUMN FLANGE 2" 2" FOR L4x4 2 1/2" FOR L5x5 1 1/2" 12" 1 1/2" 2" MIN 4 1/4" 2L, SEE NOTE 1 BOLTS, SEE NOTE 1 2L4x4 2" MIN OF WEB 1/2" TO FACE MAX COPE LENGTH 3" OC TYP
