An incoming structural connection is joined to a column centerline using a three-and-a-half-inch Grade 65 flange plate secured by ninety-six one-and-one-quarter-inch Group B bolts in standard holes. The connection features a three-quarter-inch maximum overslot with four-inch on-center bolt spacing. Edge distances and fastener groups are dimensioned symmetrically about the column centerline.
CL COL OVERSLOT 3/4" MAX SECTION C 3"2" 4" OC 3" SPCG EQ 10" SPCG EQ 2" 3" 3" 2" FLG PL3 1/2, GR 65 W/ (96) 1 1/4" GROUP B X BOLTS IN STD HOLES. INCOMING C1 CONN
