An HSS5x5x1/4 hollow structural section hanger connects to a W18x50 wide flange beam. A vertical drop of five feet six inches is dimensioned per note two. The framing detail serves typical brace conditions.
S12NW, SEE S2.50 HSS5x5x1/4 HANGER, TYP , TYP TYP AT BRACE W18x50 SEE NOTE 2 5' - 6" S12NW, SEE S2.50 HSS5x5x1/4 HANGER, TYP , TYP TYP AT BRACE W18x50 SEE NOTE 2 5' - 6"
