A structural connection links an existing hollow structural section (HSS6x6x1/4) and an existing W21x49 steel beam supporting a metal deck adjacent to an 8-inch concrete wall. The connection incorporates a 1/2-inch plate and requires selective demolition of existing plates above and below the HSS section. Installation procedures require removing existing 7/8-inch diameter nuts and washers after angle installation, alongside typical bolt hole spacings of 1-1/2 inches, 3 inches, and 6 inches.
DD.33 A A 6" 1" (E) BOLT HOLES TYP ES 1 1/2" 3" DD.33 (E) 8" CONC WALL (E) W21X49 (E) DECK REMOVE (E) 7/8"Ø NUT & WASHER AFTER ANGLE INSTALL REMOVE (E) 7/8"Ø NUT & WASHER DEMO PL BELOW HSS (E) PL 1/2 (E) HSS6X6X1/4 DEMO PL ABOVE HSS AFTER ANGLE INSTALL 1" = 1'-0" 8 HSS CONNECTION TO (E) BEAM & DECK
