An L5x5x3/8 angle serves as a corner brace between the concrete masonry unit wall and the tilt-up concrete wall panel, with ends attached per detail 08S4.1. Bond beam reinforcement anchors to the tilt-up wall via an adhesive anchoring system with a minimum embedment of 4 inches. Bracing intervals are dimensioned at 8 feet on center, with wall configuration and alignment per architectural plans.
Text on the drawing
1 F CMU WALL (TYP.) TILT WALL PER PLAN L5X5X3/8 CORNER BRACE (TYP.) - ATTACH ENDS OF BRACES PER DETAIL 08S4.1 ANCHOR BOND BEAM REINF. TO TILT WALL W/ ADHESIVE ANCHORING SYSTEM - EMBED 4" MIN. (TYP.) GRID GRID TYP. 08 S4.1 TYP. 08 S4.1 SIM. PER ARCH. PER PLAN (TYP.) 8'-0" (TYP.) 8'-0"
