A timber framing member with a notched inside face connects to a column cap plate below. Bolts secure the assembly as specified per detail 3/s-902, with the wood inset notched as required typically.
B PLAN A B O.H. 3 1 O.H. CAP PL & COL BELOW BOLTS PER 3/s-902, NOTCH INSIDE FACE OF WOOD INSET AS REQ'D, TYP.
