A splice connection for hollow structural sections sized per plan utilizes two 1-inch by 1-3/4-inch by 1'-6" long steel plates welded to each side of the hollow structural section with 1/4-inch fillet welds of varying lengths. A maximum 1/2-inch gap is permitted at the splice where it occurs. Section C-C provides the profile of the hollow structural section with the splice plates attached to each side.
1/2" MAX SPLICE WHERE OCCURS HSS SEE PLAN HSS SEE PLAN C-C PL 1"x1 3/4"x1'-6" LONG EA SIDE C-C SECTION 1'-6" MAX 1/4 8 1/2 TYP EA PL 1/4 1" TYP EA PL 8 1/2
