A make-up air unit weighing up to 3500 pounds is suspended using three 1/2-inch diameter hanger rods on each side, uniformly spaced along the unit. The unit is supported below by hollow structural section HSS2x2x1/4 bottom supports and an HSS4x4x1/4 cross beam. Wide flange beams per plan tie into the framing assembly. Simpson L50 clips are anchored with two per side for a total of eight at the exterior wall. A weld callout references sheet S1.6 for field connections.
1 2" 4 3 2 10 1/2" SEE S1.6 1 MAU UNIT PER MECHANICAL (MAX WEIGHT = 3500#) 3 (3) 1/2" DIA. HANGER ROD EA SIDE LOCATE HANGERS UNIFORMLY SPACED ALONG MAU. 4 HSS4x4x1/4 CROSS BEAM 5 HSS2x2x1/4 BOT SUPPORTS 6 EXTERIOR WALL PER PLAN 7 SIMPSON L50 CLIP (2) PER SIDE, (8) TOTAL @ WALL 2 WF BEAM PER PLAN
