Structural · S-CFAFN

Braced Frame Baseplate Detail

Materials

Elements

Floors / Slabs Bracing Connections / Plates Reinforcing

Connections

Braced Frame Connection Gusset Plate Base Plate / Anchorage Bracing Connection Welded Connection Bolted Connection Rebar Splice / Development

About this detail

A buckling-restrained brace connects to a steel base plate anchored atop a reinforced concrete footing. The base plate is seated on a one-inch layer of non-shrink grout within a footing pocket. Anchor rods extend twenty-five inches minimum into the concrete footing, secured with nuts at the bottom. Additional reinforcing bars of size number eight by twenty feet long are placed each way, twelve total, centered on the base plate. Buckling-restrained braces connect to the gusset plate and base assembly via welded connections per the manufacturer requirements.
