A heavy structural steel base plate connection secures the column and gusset plate assembly using twelve 1-3/4 inch diameter anchor rods. The two-and-one-quarter-inch thick base plate measures sixty-four by twenty-four inches and is detailed per sheet S-202. Anchor rods are distributed symmetrically around the perimeter of the L-shaped footprint with precise edge distances and spacing dimensions indicated.
10" 10" 10" 10" 3" 1'-8" 1'-8" 1'-8" 5" 5" 1'-8" 1'-8" 1'-8" 3" 10" 10" 10" 10" 5'-8" 2'-2" 3" 1'-8" 3" 3" 1'-8" 3" 2'-2" 5'-8" (12) 1 3/4" Ø ANC RODS, SEE DET -------- 2 1/4" x 64" x 24" BASE PL 3/S-202 H 3
