This structural steel connection details a buckling-restrained braced frame double brace intersecting a beam and column moment connection. The gusset plates are sized per the BRBF manufacturer and welded to the framing, featuring typical one-inch by one-inch snips and five-sixteenth-inch fillet welds. One-half-inch stiffener plates are provided on both sides of the beam web where required. Complete joint penetration welds are specified at the column connections, with weld backing removal and backgouging to sound weld metal where noted. Connection bolts for the braces are provided by others as indicated on plan.
WORK POINT COLUMN - SEE PLAN CONNECTION BOLTS - BY OTHERS BRB - BY OTHERS GUSSET PL - SIZE PER BRBF MANF'R. WELD PER BRB MANF'R CL CL SNIP (1"x1"), TYP. BRACED FRAME MOMENT CONNECTION - SEE & BEAM - SEE PLAN PL1/2 STIFF. PL, BOTH SIDES, TYP. 5/16 SEE NOTE 1 COL. - WHERE OCCURS EQ. EQ. 5/16 5/16 TYP. CJP, TYP. NOTE: REMOVE WELD BACKING, BACKGOUGE TO SOUND WELD METAL AND ADD 5/16" MIN. FILLET WELD (REMOVAL OF WELD BACKING NOT REQUIRED WHERE GUSSET PLATE OCCURS). 3 S-5124 4 S-5124
