A buckling restrained brace connection frames into a continuous steel beam with a concrete over metal floor or roof deck. The assembly features a gusset plate and steel core designated as a protected zone, with brace connection size and location delegated to the buckling restrained brace supplier. Stiffener plate size, number, and location are also designed by the buckling restrained brace supplier. The work point aligns with the centerlines of the intersecting structural steel members, with additional framing configurations referenced on the braced frame elevation.
STIFF PL NUMBER, SIZE AND LOC TO BE DESIGNED BY BRB SUPPLIER BRACE CONNECTION DESIGN BY BRB SUPPLIER PROTECTED ZONE IS GUSSET PL AND STL CORE STL BM BUCKLING RESTRAINED BRACE, TYP BM CONC OVER MTL FLR DECK WP SEE BRACED FRAME EL FOR ADDITIONAL INFO CONNECTION FOR BM NS OR FS, SEE PLAN OR ROOF DECK
