A concrete slab bears on a reinforced concrete grade beam supported by a screw pile. HD12 epoxy starter bars are spaced at 200 millimeters center-to-center at the entrance with a 100-millimeter embedment into the grade beam. The exterior grade slopes away from the slab nosing, and the concrete surface is roughened. Sheetpiling is installed by others adjacent to the grade beam, with the screw pile located beyond.
2083 2500 AT 'SIM' 1000 7 SCREW PILE BEYOND SHEETPILING BY OTHERS EXTERIOR GRADE SEE DETAIL FOR TYPICAL GRADE BEAM INFO / 2 S4.3 NIB PER ARCH AND / 4 S4.0 SLOPE PER ARCH HD12 EPOXY STARTERS AT 200 C/C AT ENTRANCE, 100mm EMBED. TO GRADE BEAM SLAB NOSING - SEE ARCH ROUGHEN SURFACE 150 SLAB THICKNESS MIN
