Structural · S-C9SR9

Elevation - Glb Sleeper

Materials

Concrete Timber / Wood

Elements

Doors Floors / Slabs Decks Arches Reinforcing

Connections

Timber / Mass-Timber Connection

About this detail

A glulam sleeper connection sits atop cross-laminated timber flooring, featuring three-ply and five-ply CLT panels secured with a continuous L8x6x1/2 angle fastened using two rows of five-sixteenth inch diameter by three-and-one-eighth inch MTC assembly kombi screws at four inches on center staggered on each leg. A Simpson FCB43.5 bracket fastened with number twelve self-drilling screws ties into the assembly near the door threshold. An alternate condition incorporates an HSS6x4x1/4 member spanning four feet maximum with HSS4x4x1/4 at each end, supporting a concrete topping over a bent three-eighths-inch plate and terrace deck. Plywood shims up to one-half inch thick are provided as required, with lateral tie plates placed per plan beyond. The glulam sleeper elevation view contains timber members joined with two five-sixteenth inch diameter by six-and-one-quarter inch MTC vertical cylinder screws spaced at four inches on center.
