An existing hollow structural section column bears on a two-inch by thirty-five-inch by two-foot-one-inch base plate anchored to a concrete footing. The assembly is secured by four one-and-one-quarter-inch diameter by four-foot-long anchor bolts and includes a two-inch by five-inch by two-foot-one-inch shear key plate beneath. Non-shrink grout levels the base plate over the concrete footing. A new shear tube is connected per the structural schedule, and additional information is referenced on sheet S502.
1' - 3 1/2" (E) PL 2x35x2'-1" (E) HSS COLUMN A A (E) NON-SHRINK GROUT (E) CONC. FOOTING (E) (4) 1 1/4"Øx4'-0" ANCHOR BOLTS SECTION A-A TYP. 4 1/2" (E) PL 2x5x2'-1" SHEAR KEY 1' - 3 1/2" CL CL TYP. 4 1/2" (N) SHEAR TUBE REF. SCHEDULE TYP. NOTE: REF. 1/S502 FOR INFORMATION NOT SHOWN
