New threaded rods or deformed bar anchors are embedded into existing concrete by drilling a hole one-eighth inch larger than the diameter of the dowel or bolt and securing it with an approved epoxy adhesive. Minimum embedment lengths and lap splices conform to the general structural notes. Installation follows all manufacturer recommendations and project specifications.
STRUCTURAL NOTES LAP PER GENERAL EMBEDMENT LENGTH EMBEDMENT LENGTH EXISTING CONCRETE NEW THREADED ROD. DRILL AND EPOXY INTO EXISTING CONCRETE. REBAR OR DBA. DRILL AND EPOXY INTO EXIST. CONCRETE DRILL HOLE WITH DIAMETER 1/8'' LARGER THAN THE DIAMETER THE DOWEL OR BOLT. SEE GSN FOR PERMISSIBLE ADHESIVES. FOLLOW ALL MANUFACTURERS RECOMMENDATIONS & SPECIFICATIONS.
