An incoming horizontal truss connects to a structural steel column using a shear plate and top and bottom stiffener plates sized per the horizontal truss schedule. Complete joint penetration welds secure the connection components to the column flange. Connection plates are provided as required per the horizontal truss schedule for incoming beam and truss connections.
STIFF PL T&B & SHEAR PL AS REQD FOR INCOMING BM CONN STL COL, SEE SCHED CONN PL PER HORIZ TRUSS SCHED CJP SECTION C STIFF PL T&B & SHEAR PL AS REQD FOR INCOMING BM CONN STL COL, SEE SCHED CONN PL PER HORIZ TRUSS SCHED CJP SECTION C
